• Android 7.1
  • Fingerprint recognition
  • 4G/Dual-band Wi-Fi
  • High-performance scanner
  • Print
  • OCR
  • Face recognition
  • 5.0”screen
ALL-IN-ONE

RFID Reading and Writing; 1D/2D Barcode Scanning

HD camera for high resolution photos, Instant Thermal Printing

2.4GHz &5GHz Wi-Fi, 4G/LTE, GPS+BDS

Optional Fingerprint Module, PSAM Encryption





Instant-Printing

More Efficient

1D/2D barcode, while scanning while printing
Thermal printing barcodes, receipts and stickers instantly
Printing Speed–up to 40mm / sec
Make inspection, ticketing and inventory more efficient


10 hours working battery

4000mAh large battery

The dual-row power supply design can meet the high demand for power during scanning and printing.

Full-function working for more than 10 hours to ensure sufficient work power.


                   Fingerprint module certified by

                   the FBI

                             Optionally integrated TCS1 silicon fingerprint sensor

                             certified by the FBI
                             More suitable for the government, banks, financial

                             institutions and other places with high needs of

                             security

Highly integrated design for widely industry applications
Barcode/RFID/PSAM/NFC/Camera/Printer

Convenience Store Fresh Management

Instantly print fresh labels, update product status, reduce outdated losses, and have been widely used in fresh food management at major convenience stores


                    Smart Parking

                             Support thermal printing, self-adhesive printing and

                             OCR identification, which can be used for various

                             parking lot charge management.





Municipal Transportation

Highly integrated barcode scanning, NFC, RFID, has many successful cases in bus ticket sales, transportation deduction and other fields.

Applications
Highly integrated product function design, meet customer needs in various industries.
  • Medical Waste Medical Waste
  • Agriculture Agriculture
  • Manufacturing Manufacturing
  • Retail Retail
  • Financial Financial
  • Ticketing Ticketing
Specifications
  • Physical Parameter
    Size 220*93*39mm(L×W×H)
    Weight 386g (including battery)
    Display 5.0 inch
    IPS screen Resolution: 1280x720
    Touch panel Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
    Backlight LED Backlight
    Battery Li-Polymer 4000mAh
    Card slot 2 slot for SIM
    2 slots for PSAM and 1 slot for Micro SD (Maximum 128G)
    Communication interface Micro USB 2.0, OTG
    Network connections 4G/3G/2G, Wi-Fi, GPRS, Bluetooth, GPS, BDS
    Keyboard On-screen Keyboard+3Virtual Keys: Back, Home and Menu
    Printing 2” 384 thermal print head
    Print speed: 20mm/s
    Communication
    WWAN GSM:850/900/1800/1900 WCDMA:B1/B2/B5/B8 TDS-CDMA:B34/B39 LTE_TDD:B38/B39/B40 LTE_FDD:B1/B3/B7/B8/B
    Wi-Fi Wi-Fi frequency: 2.4GHz & 5GHz
    Wi-Fi protocol: 802.11a/b/g/n/ac
    GPS GPS/BDS/GLONASS, A-GPS
    Bluetooth Bluetooth 4.0+EDR
  • IoT Functions
    NFC Fully support NFC, 14443A/B, 15693 Protocol
    Reading Distance 2cm~5cm, reading position, battery cover
    RFID Fully support NFC, 14443A/B、15693 Protocol
    Reading Distance 2cm~5cm, reading position, battery cover
    Support UHF RFID (920MHz-925MHz) , EPC C1/G2, ISO 18000-6C Protocol
    Security PSAM Supporting 2 PSAM cards
    Sensors Light sensor, proximity sensor, gravity sensor, Hall sensor (optional)
    Camera
    Camera Front camera:2-megapixel
    Rear camera:8-megapixel auto-focusing ; with LED light, support flashlight
    Performance
    CPU Octa-core 2.5GHz
    OS Android 7.1
    Memory 2GB RAM/16GB ROM
    Barcode Scanning
    2D Scanner Zebra/Honeywell scanning engine
    1D Symbologies UPC / EAN , Bookland EAN , UCC Coupon Code , ISSN EAN , Code 128 , GS1 - 128 , ISBT128 , Code39 , Trioptic Code39 , Code32 ,Code93 , Code11 , I nterleaved 2 of 5 , Discrete 2 of 5 , Codabar , MSI , Chinese 2 of 5 , Korean 3 of 5 , Matrix 2 of 5 , Inverse 1D , GS 1 DataBar , Composite Codes . etc
    2D Symbologies PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverse, Han Xin, Han Xin Inverse, etc.
