• Android 7.1/9.0
  • Octa-core 2.5GHz
  • 5.5” screen
  • 3GB RAM/32GB ROM
  • 4G/Dual-band Wi-Fi
  • IP67
  • RFID
  • High-performance scanner


CILICO THOR™

Stable & reliable
Leader in industry

          1-3m

          Ultra-long UHF Reading Distance

               Support UHF global frequency

               1D/2D scanning, and NFC all-in-one

               Smart and powerful

Excellent Scanning Performance

Adopt the industry's leading scanning engine to give users a faster and more efficient scanning experience

      IP67 Protection Grade

         Military defense quality, dustproof, waterproof, anti-fall 6 sides can

         withstand the multiple 1.5m (5 ft) drops to concrete IP67 rated

         protection, can be fully immersed in water depth of 1.5 meters

Highly integrated design for widely industry applications
Barcode/RFID/PSAM/NFC/Camera

Extensive Industry Application

Highly integrated product design, integrated built-in barcode scanning, UHF, NFC information reading functions, one device can meet the reading of multiple tag types in complex environments.

Professional Logistics

Read all kinds of tag information in complex environments such as aviation, port and railway freight

Intelligent

Manufacturing

Flexible programming, can be connected with mainstream WMS, MES system management software,Excellent protection performance can meet the use of various harsh conditions.


Intelligent Inspection

Excellent 4G communication performance, high-definition dual-camera configuration, and excellent protection level can meet the needs of harsh power inspections.

Applications
F880 series mobile computers are widely deployed in airport cargo,warehouse management, logistics, state grid solutions etc.
  • Logistics Logistics
  • Warehouse Warehouse
  • Manufacturing Manufacturing
  • Inspection Inspection
  • Airport Cargo Airport Cargo
  • Energy Energy
Specifications
  • Physical Parameter
    Size 180mm×84mm×21mm (L×W×H)
    Weight 380g (including battery)
    Display 5.5 inch, IPS screen Resolution: 1920x1080
    Touch panel Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
    Backlight LED Backlight
    Battery Li-polymer, 5700mAh
    Uptime: more than 8 hours
    Standby time: 300 hours
    Card slot 1 slot for SIM
    2 slots for PSAM
    1 slot for Micro SD (Maximum 128G)
    Communication interface Type-c, OTG
    Network connections 4G/3G/2G, Wi-Fi, GPRS, Bluetooth, GPS, BDS, GLONASS
    Keyboard On-screen Keyboard+3 Virtual Keys: Back, Home and Menu
    Performance
    CPU Octa-core 2.5GHz
    OS Android 7.1/9.0
    Memory 3GB RAM/32GB ROM
    Communication
    WWAN GSM/GPRS/WCDMA/CDMA/ TD-SCDMA/TDD-LTE/FDD-LTE
    Wi-Fi Wi-Fi frequency: 2.4GHz & 5GHz
    Wi-Fi protocol: 802.11a/b/g/n/ac
    GPS GPS/BDS/GLONASS
    Bluetooth Bluetooth 4.2
  • IoT Functions
    NFC Operating frequency: 13.56MHz
    Support protocol: MifareClassic (MF1), NDEF, NfcV (15693), Ultralight (MF0), IsoDep (Quas:CPU MF3), IsoDep (CPU)
    Reading distance: 0-5cm
    (depending on the card type)
    RFID Operating frequency:
    US: 902-928MHz
    EU: 865-868MHz
    JP:916-921MHz(w LBT)
    JP:916-923MHz
    Support protocol: ISO18000-6C/EPC C1G2
    Reading distance:3m
    (depending on the label)
    Security PSAM Supporting ISO7816 standard
    Supporting 2 PSAM cards
    Sensors Light sensor, proximity sensor, gravity sensor, Hall sensor (optional)
    Camera
    Camera Front camera: 2 MP
    Rear camera:8 MP,
    auto-focusing; support flashlight
    Barcode Scanning
    2D Scanner Zebra/Honeywell scanning engine
    1D Symbologies UPC/EAN, Bookland EAN, UCC Coupon Code, ISSN EAN, Code 128, GS1-128, ISBT 128, Code 39, Trioptic Code 39, Code 32, Code 93, Code 11, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, Korean 3 of 5, Matrix 2 of 5, Inverse 1D, GS1 DataBar, Composite Codes, etc.
    2D Symbologies PDF417, MicroPDF417, Data Matrix, Data Matrix I nverse,Maxicode, QR Code, MicroQR, QRinverse, Aztec, Aztec Inverse, Postal Codes: USPostnet, US Planet, UK Postal, Australian Postal, Japan Postal, Netherlands KIX Code, USPS 4CB/One/ Intelligent Mail, UPS FICS Pstal, etc.
