GMS
-
Android 7.1/9.0
-
Octa-core 2.5GHz
-
5.5” screen
-
3GB RAM/32GB ROM
-
IP67
-
RFID
-
High-performance scanner
CILICO THOR™
Stable & reliable
Leader in industry
1-3m
Ultra-long UHF Reading Distance
Support UHF global frequency
1D/2D scanning, and NFC all-in-one
Smart and powerful
Excellent Scanning Performance
Adopt the industry's leading scanning engine to give users a faster and more efficient scanning experience
IP67 Protection Grade
Military defense quality, dustproof, waterproof, anti-fall 6 sides can
withstand the multiple 1.5m (5 ft) drops to concrete IP67 rated
protection, can be fully immersed in water depth of 1.5 meters
Extensive Industry Application
Highly integrated product design, integrated built-in barcode scanning, UHF, NFC information reading functions, one device can meet the reading of multiple tag types in complex environments.
Professional Logistics
Read all kinds of tag information in complex environments such as aviation, port and railway freight
Intelligent
Manufacturing
Flexible programming, can be connected with mainstream WMS, MES system management software，Excellent protection performance can meet the use of various harsh conditions.
Intelligent Inspection
Excellent 4G communication performance, high-definition dual-camera configuration, and excellent protection level can meet the needs of harsh power inspections.
-
Logistics
-
Warehouse
-
Manufacturing
-
Inspection
-
Airport Cargo
-
Energy
-
Physical Parameter Size 180mm×84mm×21mm (L×W×H) Weight 380g (including battery) Display 5.5 inch, IPS screen Resolution: 1920x1080 Touch panel Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported Backlight LED Backlight Battery Li-polymer, 5700mAh
Uptime: more than 8 hours
Standby time: 300 hoursCard slot 1 slot for SIM
2 slots for PSAM
1 slot for Micro SD (Maximum 128G)Communication interface Type-c, OTG Network connections 4G/3G/2G, Wi-Fi, GPRS, Bluetooth, GPS, BDS, GLONASS Keyboard On-screen Keyboard+3 Virtual Keys: Back, Home and Menu Performance CPU Octa-core 2.5GHz OS Android 7.1/9.0 Memory 3GB RAM/32GB ROM Communication WWAN GSM/GPRS/WCDMA/CDMA/ TD-SCDMA/TDD-LTE/FDD-LTE Wi-Fi Wi-Fi frequency: 2.4GHz & 5GHz
Wi-Fi protocol: 802.11a/b/g/n/acGPS GPS/BDS/GLONASS Bluetooth Bluetooth 4.2 -
IoT Functions NFC Operating frequency: 13.56MHz
Support protocol: MifareClassic (MF1), NDEF, NfcV (15693), Ultralight (MF0), IsoDep (Quas:CPU MF3), IsoDep (CPU)
Reading distance: 0-5cm
(depending on the card type)RFID Operating frequency:
US: 902-928MHz
EU: 865-868MHz
JP：916-921MHz(w LBT)
JP：916-923MHz
Support protocol: ISO18000-6C/EPC C1G2
Reading distance:3m
(depending on the label)Security PSAM Supporting ISO7816 standard
Supporting 2 PSAM cardsSensors Light sensor, proximity sensor, gravity sensor, Hall sensor (optional) Camera Camera Front camera: 2 MP
Rear camera：8 MP,
auto-focusing; support flashlightBarcode Scanning 2D Scanner Zebra/Honeywell scanning engine 1D Symbologies UPC/EAN, Bookland EAN, UCC Coupon Code, ISSN EAN, Code 128, GS1-128, ISBT 128, Code 39, Trioptic Code 39, Code 32, Code 93, Code 11, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, Korean 3 of 5, Matrix 2 of 5, Inverse 1D, GS1 DataBar, Composite Codes, etc. 2D Symbologies PDF417, MicroPDF417, Data Matrix, Data Matrix I nverse,Maxicode, QR Code, MicroQR, QRinverse, Aztec, Aztec Inverse, Postal Codes: USPostnet, US Planet, UK Postal, Australian Postal, Japan Postal, Netherlands KIX Code, USPS 4CB/One/ Intelligent Mail, UPS FICS Pstal, etc.
-
